High power 100W ultra band 300-2700MHz PA power amplifier module For government projects

High power 100W ultra band 300-2700MHz PA power amplifier module For government projects
High power 100W ultra band 300-2700MHz PA power amplifier module For government projects
High power 100W ultra band 300-2700MHz PA power amplifier module For government projects High power 100W ultra band 300-2700MHz PA power amplifier module For government projects High power 100W ultra band 300-2700MHz PA power amplifier module For government projects
Informação Básica
Lugar de origem: Guang Dong CHINA
Marca: Texin
Minimum Order Quantity: 1
Preço: Negociável
Packaging Details: Durable box
Tempo de entrega: 5-7 dias úteis
Termos de pagamento: TT ustd wechat paypal
Habilidade da fonte: mês 1000000/per
Melhor preço contacto
Informação detalhada
Potência: 100W Faixa de frequência: 2.000-7.200 MHz
Função: Ampla cobertura 2.000-7.200 MHz Tensão de alimentação: 28 v
Ganho: 50dBM Garantia: 1 ano
Aplicativo: Comunicação sem fio, radar, equipamento de teste Conector: Tipo N
Destacar:

100W broadband power amplifier module

,

300-2700MHz PA power amplifier

,

government project power amplifier

Descrição de produto

High Power 100W Ultra Band 300-2700MHz PA Power Amplifier Module For Government Projects
Product Overview

The high-power 100W 2000-7000MHz amplifier is an advanced, wide-bandwidth security device designed to counter illegal low-altitude drones. Manufactured in Guangdong, China, this power amplifier features 5dBm input power and a broad frequency range of 2000MHz to 7000MHz, making it ideal for various applications including drone countermeasures systems, wireless communications, radar systems, and testing equipment.

With 50-ohm output impedance for optimal signal transmission and minimal loss, this amplifier provides reliable performance in critical frequency bands. Texin operates its own factory, enabling customization of existing products and development of new solutions based on customer requirements.

Key Features
  • Product Name: Broadband Power Amplifier
  • Input: 5dBm
  • Warranty: 1 Year
  • High linearity for superior signal quality
  • Brand: Texin
  • Wattage: 100W
  • Supports 50W and 100W power amplifier configurations
  • Frequency range: 2000-7000MHz power amplifier
  • Ideal for drone defense power amplifier applications
Technical Specifications
Description Symbol Min Typ Max Unit Remark
Operating Frequency BW 2000 7200 MHz
Input Power Pin 0 dBm
Output Power CW Psat 50 50.5 52 dBm Continuous Wave
Power Gain Gp 50.5 dBm @ Pin=0 dBm
Power Gain Flatness △Gp ±1.5 dB @ Pin=0 dBm
Input Return Loss S11 -15 dB
Operating Voltage Vdc 28 28 36 V
Current Consumption A 15 18 A @ Pout=100~160W
RF Connector Input SMA, Female
RF Connector Output SMA, Female
Max Input Power PinMax ≤10 dBm
Interface Definition
Interface Pin Definition
VDD A2 28Vdc
GND A1 Ground
Enable 1 5V~Vdd:ON 0V:OFF

Note: Overall dimensions are for reference only. Size can be adjusted according to customer requirements. Input, output, and power supply interface positions can be modified based on actual needs.

Applications
  • Used by national security departments to protect national security and leader safety
  • Radio frequency testing, data collection, and new product development
  • Signal transmission in satellite and radar applications
Product Images
High power 100W ultra band 300-2700MHz PA power amplifier module For government projects 0 High power 100W ultra band 300-2700MHz PA power amplifier module For government projects 1 High power 100W ultra band 300-2700MHz PA power amplifier module For government projects 2 High power 100W ultra band 300-2700MHz PA power amplifier module For government projects 3 High power 100W ultra band 300-2700MHz PA power amplifier module For government projects 4
Frequently Asked Questions
What is the brand of the Broadband Power Amplifier?
The Broadband Power Amplifier is manufactured by Texin.
Where is the Broadband Power Amplifier produced?
It is produced in Guang Dong, China.
What is the minimum order quantity for this product?
The minimum order quantity is 1 unit.
What are the payment terms available?
Payment can be made via TT, USD T/T, WeChat, or PayPal.
How long does delivery take after placing an order?
Delivery time is typically 5-7 working days.
How is the product packaged for shipping?
The Broadband Power Amplifier is packaged in a durable box to ensure safe delivery.
What is the monthly supply capacity of Texin for this product?
Texin can supply up to 1,000,000 units per month.
Is the price fixed or negotiable?
The price is negotiable depending on order quantity and specifications.
